Description
Technical specifications
| Laser diode: | red |
| Visible laser beam: | red |
| Self-levelling range: | ± 5° |
| Accuracy horizontal: | ± 0,75 mm / 10 m |
| Accuracy vertical: | ± 1,0 mm / 10 m |
| Working range without receiver: | Ø 40 m |
| Working area with FR 45: | Ø 1200 m |
| Working area with FR 77-MM: | Ø 600 m |
| Working area with FR-DIST 30: | Ø 600 m |
| Working range remote control: | IR 100 m |
| Grade: | numerisch |
| Slope setting manual X-Axis: | ± 5° (± 9%), + 0.1 to 6.9% (at 0.1% step) |
| Vertical axis direction: | ± 5° |
| Laser class: | 2 |
| Rotating speed rpm: | 800 |
| Operating time: | 40 h |
| Dust / water protection: | IP 66 |
| 90° plumb beam up: | yes |
| Automatic TILT function: | yes |
| Temperature range: | -10°C to +50°C |
| VWS function: | yes |
Supplied with
- Receiver FR 50 with clamp
- Remote control
- Rechargeable battery (Li-Ion)
- Intelligent battery charger
- Battery case for alkaline batteries
- Floor / wall mount (integrated)
- Carrying case
